Ortofon 2M Red

Ortofon 2M RED

Hover over an image to enlarge

95,00
(Including tax)
In stock
+
2M Red

2M Red features:

- an improved engine, which provides an increased output of 5.5mV and an optimized sound reproduction and a high level of sonic accuracy

- a tipped Elliptical diamond and split pole pins with a copper wire

2M Red is an all-purpose cartridge that delivers open, dynamic sound with a slight touch of warmth.



2M Red accessories included in the package:

  • 1 x Stylus brush
  • 1 x Screwdriver
  • 2 x Screw M2,5 x 5
  • 2 x Screw M2,5 x 7



2M Red Technicale data:

Output voltage at 1000 Hz, 5cm/sec.  -  5,5 mV
Channel balance at 1 kHz   -  1,5 dB
Channel separation at 1 kHz  -  22 dB
Channel separation at 15 kHz  -  15 dB
Frequency range at - 3dB  -  20-22.000 Hz
Frequency response  -  20-20.000 Hz + 3 / - 1 dB
Tracking ability at 315Hz at recommended tracking force  -  70 µm
Compliance, dynamic, lateral  -  20 µm/mN
Stylus type  -  Elliptical
Stylus tip radius  -  r/R 8/18 µm
Tracking force range  -  1,6-2,0g (16-20 mN)
Tracking force, recommended  - 1,8 g (18 mN)
Tracking angle  -  20°

Internal impedance, DC resistance  -  1,3 kOhm
Internal inductance  -  700 mH
Recommended load resistance  -  47 kOhm
Recommended load capacitance  -  150-300 pF
Cartridge colour, body/stylus  -  Black/Red
Cartridge weight  -  7,2 g
Replacement stylus unit  -  2M Red (interchangeable with 2M Blue and 2M Silver)
