AT-XP5
Dual Moving Magnet-stereo-cartridge DJ
The AT-XP5 is specially designed for the needs of DJs. This cartridge features a highly-rigid polyphenylene sulfide (PPS)/glass fiber body and a tracking force of 2 to 4 grams. It also offers a powerful output level of 5.5 mV, and its 0.3 x 0.7 mil elliptical bonded stylus tracks the record groove with high accuracy for outstanding audio reproduction. Plus, the cartridge is specifically designed to provide maximum visibility of the stylus tip.
Features
- 0.3 x 0.7 mil elliptical bonded stylus tip
- Highly-rigid polyphenylene sulfide (PPS)/glass fiber body
- 5.5 mV high-level output
- Tracking force of 2.0 to 4.0 grams (3.0 grams standard)
- Durable carbon fiber-reinforced ABS cantilever and nylon wire suspension ensure precise tracking
- Design offers maximum visibility of the stylus tip
- Great tracking and channel separation for high-fidelity sound
Specifications
Frequency Response | 20-18,000 Hz |
Channel Separation | 20 (dB at 1 kHz) |
Vertical Tracking Angle | 20° |
Vertical Tracking Force | 2.0-4.0 g (3.0 g standard) |
Stylus Construction | Bonded round shank |
Recommended Load Impedance | 47,000 ohms |
Coil Impedance | 6.7 k ohms (1 kHz) |
DC Resistance | 990 ohms |
Coil Inductance | 1.0 H (1 kHz) |
Recommended load capacitance | 100 to 200 pF |
Output | 5.5 mV (1 kHz, 5 cm/sec.) |
Channel Balance | 2.0 dB (1 kHz) |
Stylus Shape | 0.3 x 0.7 mil elliptical |
Cantilever | Carbon fiber-reinforced ABS |
Mount | Half-inch |
Weight | 6.2 g (0.22 oz) |
Dimensions | 17.2 mm (0.68") H × 17.8 mm (0.67") W × 28.3 mm (1.20") D |
Replacement Stylus | ATN-XP5 |
